OUR PRODUCTS
XVR7216A-4KL-X
Dahua XVR7216A-4KL-X pro series penta-brid 4K uhd 16ch@8Mpx 5IN1 HDCVI/AHD/HDTVI/PAL/IP h.265+ p2p alarm ivs iot
- Standard CCTV Technology Support: CVBS/HDCVI/HDTVI/AHD + IP@8Mpx (Max. 16 IP) Onvif 16.12
- HDCVI Camera resolution: 4K@7fps, 6Mpx@10fps, 5Mpx@12fps, 4Mpx@15fps, 1080P@15fps, 1080N@25/30fps, 720P@25/30fps, 960H@25/30fps.
- AHD Camera resolution: 5Mpx@12fps, 4Mpx@15fps, 1080P@15fps, 1080N@25/30fps, 720P@25/30fps, 960H@25/30fps.
- HD-TVI Camera resolution: 5Mpx@12fps, 4Mpx@15fps, 1080P@15fps, 1080N@25/30fps, 720P@25/30fps, 960H@25/30fps.
- Video signal transmission over long distances (800-1100m), using coaxial cable.
- Management by XVR via coax cable. the OSD and PTZ camera movement.
- Recording (REC & Live) on all channels in 4K ULTRA HD.
- Video compression H.265+/H.265/H.264+/H.264 dual-stream
- 1/4/8/9/16 channels (IP extension not active) or 1/4/8/9/16/25 (active IP extension), GRID interface and intelligent search
- 3D intelligent positioning with Dahua PTZ dome camera - RS485 port for classical analog PTZs.
- Support and Programming of SMART & Video Analysis IVS : Tripwire, Intrusion (for all channels), Abandoned / Missing, Face Detection. (Crossing lines | Intrusion in the air | Abandoned object | Detecting faces). Programmable on all channels (up to 10 rules per channel (Max.4)). Face Detection (on the first channel only) and Smart Search.
- POS Function (Point of Sale Terminal): This funcion includes POS ticket information overlay and search which can be widely used in retail program.
- IoT Functionality: HDCVI IoT can achieve multi-dimensional surveillance by integrating sensors with monitoring video, which not only can generate the report for analysis but also prevent risk in advance.
- New simplified and intelligent graphical interface (version HDCVI 5.0) - Smart Fan / Coax. Audio functions.
- It Supports 2 SATA HDD up to 10TB, 2 USB Ports (1 USB 2.0 , 1 USB 3.0)
- Supports 4 Input / 1 Output RCA Audio - Two-way Talk.
- 16 inputs + 3 relay alarm outputs
- Multiple network monitoring: Web viewer, CMS (DSS / PSS Smart) Smartphone (DMSS)
- Easy Setup P2P QR scan with Cloud service dedicated Dahua.
- ONVIF Version 16.12, CGI Conformant
HAC-HDW1801T-Z-A-27135
Lite Plus Series | DH-HAC-HDW1801T-Z/T-Z-A www.dahuasecurity.com DH-HAC-HDW1801T-Z/T-Z-A 4K HDCVI IR Eyeball Camera System Overview Experience 4K video surveillance with the simplicity of reusing existing coaxial infrastructure. The 4K HDCVI camera adopts a powerful Dahua ISP and advanced 1/2.7" CMOS sensor, which provides superior high quality images. In addition, the camera features broadcastquality audio to provide enhanced supplementary evidence collection. Ultra-high definition and a complete set of features makes the 4K HDCVI camera an ideal choice for mid to large-size businesses and projects where both highly reliable surveillance and construction flexibility are demanded. Functions 4 Signals over 1 Coaxial Cable HDCVI technology supports 4 signals to be transmitted over 1 coaxial cable simultaneously, i.e. video, audio*, data and power. Dual-way data transmission allows the HDCVI camera to interact with the HCVR, such as sending control signal or triggering alarm. Moreover, HDCVI technol- ogy supports PoC for construction flexibility. * Audio input is available for some models of HDCVI cameras. Long Distance Transmission HDCVI technology guarantees real-tim
